Light Engineered Displays EM Series User Manual
Light Engineered Displays Sensors

•
Non glare protective front
•
Sturdy, stylish low profile
frame
•
Mounts using concealed
hardware
•
Changeable graphics
The Graphic Evacuation Map consists of color-coded artwork sandwiched
between a 1/8” clear non-glare front color and a 1/8” white acrylic backup
sheet. The assembly is housed in a sturdy brushed aluminum frame and is
attached to the wall with vandal resistant hidden hardware.
Should the building floor plans or evacuation route be changed, the artwork
can be extracted and modified, or replaced to match the new requirements
without replacing the entire assembly.
Features
General Description
109 Portwatch Way Wilmington, N.C. 28412 Phone: (800) 251-2512 Fax: (800) 251-9878
Internet: www.ledinc.com Email: [email protected]
Graphic Annunciators * Water Leak Detection
Fireman’s Smoke Control Panels * ARA Systems
EM
SERIES
Model EM1212
GRAPHIC
EVACUATION MAP
