Overview
4
3 Overview
This section describes:
• The TP-107AVR/TP-122 BoardView™ kits, see
• The RC-108 and the RC-116, presentation controllers, see
Section 3.1
• Using shielded twisted pair (STP)/unshielded twisted pair (UTP), see
Section 3.2
• The Power Connect™ feature, see
Section 3.3
• Recommendations for achieving the best performance, see
Section 3.4
3.1 About the TP-107AVR/TP-122 Kits
Section 3.5
The TP-107AVR is an XGA/Audio Line Transmitter that accepts a
computer graphics 1
The TP-122 is an XGA/Audio Line Receiver
video signal and an analog audio signal and transmits
them over a CAT 5 cable.
2
You can use a single TP-107AVR unit together with the TP-122 to
configure an XGA/Audio Line to Twisted Pair Transmitter and Receiver
system.
that receives the coded CAT 5
signal transmitted by a TP-107AVR decodes it and converts it to XGA,
stereo analog and S/PDIF digital audio outputs.
The BoardView™ kits include two, four or eight 3 TP-107AVR units that
can be interconnected (via CAT 5 and K-NET™ cables) and each assigned
an address number 4 . Pressing an ONLINE button on any of the
interconnected machines transmits the signal from that machine to the
TP-122 receiver, which is also connected to the system (see Figure 1 ). The
signal is then decoded on the TP-122 and converted to an XGA output and
audio outputs. If the ONLINE button is pressed simultaneously on several
machines, the machine with the highest address number transmits the signal
to the receiver (for example, address number 5 has priority over address
number 1).
If a controller (for example, the RC-108/RC-116 Presentation Controller, see
Section 3.2
1 The terminology XGA is used throughout this manual. This implies any RGBHV signal on a 15-pin HD computer graphics
video connector having a resolution from VGA up to and including UXGA
) is connected to the BoardView™ kit, it can be used to determine
which machine in the chain has access to the TP-122.
2 You can download the Kramer TP-122 user manual at: http://www.kramerelectronics.com
3 Single TP-107AVR units can be added to a kit (up 16 units in a chain)
4 A priority number
