1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range
of problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better! Our 1,000-plus different models
now appear in 11 groups 1
Thank you for purchasing the Kramer TP-107AVR XGA/Audio Line
Transmitter, and/or the RC-108 and/or RC-116 Presentation Controllers and/or
the BoardView™ kits (specified in
that are clearly defined by function.
Table 2 ), which are ideal for presentation
and multimedia applications.
This user manual
2 is supplied with each machine (see Table 1 ) and kit (see
Table 2 ). The power supply is purchased separately 3
You can purchase single TP-107AVR machines to work as standalone units or
for adding them to a BoardView™ kit, as defined in
.
Table 1 :
Table 1: Single Units
The unit Recommended Cables
TP-107AVR One K-NET 4
RC-108
and one CAT 5 cable
One K-NET cable
RC-116 One K-NET cable
Table 2: BoardView™ Kit Options
BoardView
Kit Name
Machines
Included
Recommended Cables Recommended 5 Power
Adapter (12V DC) 6
Recommended
Controller
STP CAT 5 K-NET 7
2AVR Two TP-107AVR
One TP-122
2 1 1.25A N/A
4AVR Four TP-107AVR
One TP-122
4 3 2.1A RC-108
8AVR Eight TP-107AVR
One TP-122
8 7 5A RC-108/RC-116
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from the Internet at this URL:
http://www.kramerelectronics.com
3 For single machines as well as for the BoardView™ kits
4 Kramer model BC-2T
5 The power supply is not provided with the kit, it can be purchased separately, see
Table 3
6 Adding additional single units to a kit probably changes the power requirements, see Table 3
7 K-NET™ is a proprietary Kramer protocol for interconnecting Kramer units
