Technical Specifications
27
Table 8 details the
VS-646 and the VS-848 technical specifications
1
.
Table 8: Technical Specifications of the VS-646/VS848
INPUTS:
VS-646
6 composite video, 1Vpp/75 on BNC connectors
1 sync/video genlock 1Vpp/75 with sync select switch
6 balanced audio stereo, +4dBm/33k on detachable terminal blocks
VS-848
8 composite video, 1Vpp/75 on BNC connectors.
1 sync/video Genlock 1Vpp/75 with sync select switch
8 balanced audio stereo, +4dBm/33k on detachable terminal blocks
OUTPUTS:
VS-646
6 composite video, 1Vpp/75 on BNC connectors
6 balanced audio stereo, +4dBm/50 (24Vpp max.) on detachable terminal
blocks
VS-848
8 composite video, 1Vpp/75 on BNC connectors
8 balanced audio stereo, +4dBm/50 (24Vpp max.) on detachable terminal
blocks
MAX. OUTPUT LEVEL:
Video: 2Vpp
Audio: 24Vpp (>20dBm)
BANDWIDTH (-3dB):
Video: 200MHz
Audio: 100kHz
NON LINEARITY:
0.1%
DIFF. GAIN:
0.05%
DIFF. PHASE:
0.03Deg
K-FACTOR:
<0.05%
S/N RATIO:
Video: 74dB
Audio: 84dB unweighted (1Vpp)
CROSSTALK (all hostile): Video: -50dB @5MHz
Audio: –71.4dB @1kHz
CONTROLS:
Manual, RS-232 or RS-485
COUPLING:
Video: DC
Audio: AC
AUDIO THD + NOISE:
0.025% (1V, 1kHz)
AUDIO 2nd HARMONIC: 0.013%
POWER SOURCE:
230V AC, 50/60Hz (115V AC, USA) 9 VA
DIMENSIONS:
19” x 7” x 1U W, D, H rack mountable
WEIGHT:
3.5 kg (7.5 lbs) approx.
ACCESSORIES:
Power cord, null modem adapter, Windows®-based control software, rack
ears
OPTIONS:
External remote IR receiver cable
1 Specifications are subject to change without notice
