Technical Specifications
KRAMER: SIMPLE CREATIVE TECHNOLOGY
26
8
Technical Specifications
Table 7 details the
VS-606xl, the VS-808xl and the VS-804xl technical
specifications
1
.
Table 7: Technical Specifications of the VS-606xl/VS-808xl/VS-804xl
INPUTS:
VS-606xl
6 composite video 1Vpp/75 on BNC connectors
1 sync/video genlock 1Vpp/75 with sync select switch
6 audio stereo, +4dBm/33k on RCA connectors
VS-808xl
8 composite video 1Vpp/75 on BNC connectors
1 Sync/Video Genlock 1Vpp/75 with sync select switch
8 audio stereo, +4dBm/33k on RCA connectors
VS-804xl
8 composite video 1Vpp/75 on BNC connectors
1 Sync/Video Genlock 1Vpp/75 with sync select switch
8 audio stereo, +4dBm/33k on RCA connectors
OUTPUTS:
VS-606xl
6 composite video, 1Vpp/75 on BNC connectors
6 audio stereo, +4dBm/50 (24Vpp max.) on RCA connectors
VS-808xl
8 composite video, 1Vpp/75 on BNC connectors
8 audio stereo, +4dBm/50 (24Vpp max.) on RCA connectors
VS-804xl
4 composite video, 1Vpp/75 on BNC connectors
4 audio stereo, 4dBm/50 (24Vpp max.) on RCA connectors
MAX. OUTPUT LEVEL:
Video: 2Vpp
Audio: 20Vpp
BANDWIDTH (-3dB):
Video: 200MHz
Audio: 100kHz
NON LINEARITY:
0.1%
DIFF. GAIN:
0.05%
DIFF. PHASE:
0.03Deg
K-FACTOR:
< 0.05%
SWITCHING:
Vertical interval
S/N RATIO:
Video: 74dB
Audio: 88dB unweighted (1Vpp)
CROSSTALK (all hostile): Video: -50dB @5MHz
Audio: –71.4dB @1kHz
CONTROLS:
Manual, RS-232 or RS-485
COUPLING:
Video: DC
Audio: AC
AUDIO THD + NOISE:
0.016% (1V, 1kHz)
AUDIO 2nd HARMONIC:
0.012%
POWER SOURCE:
230V AC, 50/60 Hz (115V AC, USA) 11VA
DIMENSIONS:
19” x 7” x 1U W, D, H rack mountable
WEIGHT:
3.4 kg (7.5 lbs) approx.
ACCESSORIES:
Power cord, null modem adapter, Windows®-based control software, rack
ears, IR remote control
OPTIONS:
External remote IR receiver cable
1 Specifications are subject to change without notice
