Kramer Electronics VS-848 - Manual (Page 16)

Your Matrix Switchers
13
Table 3: Front Panel VS-646 6x6 (VS-848 8x8) Features
# Feature Function
1 IR Receiver The LED illuminates when receiving signals from the infrared remote control
transmitter
2 POWER Switch Illuminated switch for turning the unit ON or OFF
3 OFF Button An OFF-OUT combination disconnects that output from the inputs; an OFF-ALL
combination disconnects all the outputs
4 ALL Button Pressing ALL followed by an INPUT button, connects that input to all outputs 1
5 OUTPUT Buttons Select the output to which the input is switched 2
6 INPUT Buttons Select the input to switch to the output 2
7 STATUS 7-segment
Display
Displays the selected audio 3 or video 4 input switched to the output (marked
above each input 2 )
8 TAKE Button Pressing TAKE toggles the mode between the CONFIRM mode 5 and the AT
ONCE mode (user confirmation per action is unnecessary)
9 VIDEO Button When pressed, this button is illuminated and all actions relate to video
10 AUDIO Button When pressed, this button is illuminated and all actions relate to audio
11 AFV Button When pressed, this button is illuminated and all actions relate to video and
audio channels. Audio channels follow the video channels
12 STO (STORE) Button Pressing STO followed by an output button stores the current setting 6
13 RCL (RECALL) Button Pressing the RCL button and the corresponding OUTPUT key recalls a
setup from the non-volatile memory. The stored status blinks. Pressing a
different OUTPUT button lets you view 7 another setup. After making your
choice, pressing the RCL button again implements the new status
1 For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs
2 For the VS-646, 6 inputs and 6 outputs; for the VS-848, 8 inputs and 8 outputs
3 When the Audio button illuminates, that is, when the audio breakaway mode is selected
4 When the Video button illuminates, that is, when the video breakaway mode is selected
5 When in Confirm mode, the TAKE button illuminates
6 For example, press STO and then the Output button # 3 to store in Setup # 3
7 Only view, nothing is implemented at this stage
