Operating VS-808xl Matrix Switcher
KRAMER: SIMPLE CREATIVE TECHNOLOGY
24
7.3 Choosing the Audio-Follow-Video or Breakaway Option
You can switch stereo audio signals in one of two ways, either:
Audio-follow-video (AFV), in which all operations relate to both
the video and the audio channels; or
Breakaway, in which video and audio channels switch
independently
7.3.1 Setting the Audio-Follow-Video Option
To set the Audio-follow-video (AFV) option, press the AFV button. If the:
AUDIO and VIDEO configurations are the same, then the AFV
button illuminates. The audio will follow the video
AUDIO differs from the VIDEO, then the AFV button will blink.
Also, the audio outputs, that need to be changed, will blink 1 in the
INPUT STATUS 7-segment display. Press the AFV button again 2 .
The audio will follow the video, and the AFV illuminates.
7.3.2 Setting the Breakaway Option
To set the Breakaway option, press either the AUDIO (for audio control
only) or the VIDEO (for video control only) button. If the:
AUDIO button illuminates, switching operations relate to audio
VIDEO button illuminates, switching operations relate to video
7.4 Storing/Recalling Input/Output Configurations
You can store and recall up to 8 input/output setups in non-volatile memory,
using the INPUT SELECTOR buttons 3 1 to 8 (6). The 8 (6) input/output
configurations also include the relevant audio-follow-video/breakaway
option definition, the video configurations and the audio configurations.
7.4.1 Storing an Input/Output Configuration
To store the current status in memory, do the following:
1. Press the STO button.
The STO button blinks.
2. Press one of the INPUT SELECTOR 3 buttons from 1 to 8 (6). This will be
the setup # in which the current status is stored.
The memory stores the data at that reference.
1 Warning that you are about to modify the audio configuration for AFV operation
2 Failure to press the AFV button within one minute (the Timeout) will abort the action
3 For VP-606xl and VP-646, you can store up to 8 input/output configurations via RS-232
