Table 2: Rear Panel Video/Audio Matrix Switcher Features
# Feature Function
14 EXT. SYNC BNC Connector Connects to the external SYNC source
15 AUDIO INPUT RCA Connectors Connect to the audio sources 1
16 VIDEO INPUT BNC Connectors Connect to the video sources 1
17 SYNC SELECT Source Selector
Button
Pushing in selects the (EXT.) external sync source on the SYNC
connector; releasing selects the (IN 1) internal sync on the
VIDEO IN 1 connector
18 AUDIO OUTPUT RCA Connectors Connect to the audio acceptors 1
19 VIDEO OUTPUT BNC Connectors 2 Connect to the video acceptors 1
20 RS-485 Connector RS-485 port on detachable terminal block
21 RS-232 9-pin D-sub Connector Connects to the PC or other serial controller
22 Setup DIP-switches DIP 1, 2, and 3 for machine SELF ADDRESS #; DIP 4 for
RS-485 termination, DIP 5 for reply from switcher to PC,
DIP 8 for RS-232/RS-485 communication
23 Power Connector with Fuse AC connector enabling power supply to the unit
24 REMOTE IR 3.5mm Mini Jack Connect to an external IR receiver unit for controlling the
machine via an IR remote controller (instead of using the front
panel IR receiver) 3
1 For the VS-606xl, 6 inputs and 6 outputs; for the VS-808xl, 8 inputs and 8 outputs; for the VS-804xl, 8 inputs and 4 outputs
2 For RGBS applications, one of the sync channels (H or V) may be used for the S channel
3 Optional. Can be used instead of the front panel (built-in) IR receiver to remotely control the machine (only if the internal
IR connection cable has been installed)
