Connecting the VS-808xl Video/Audio Matrix Switcher
KRAMER: SIMPLE CREATIVE TECHNOLOGY
16
6 Connecting 1 the VS-808xl Video/Audio Matrix Switcher
To connect a single 2 VS-808xl switcher, as illustrated in the example in
Figure 6, do the following 3 :
1. Connect up to eight 1 composite video sources (for example, composite
video players) to the VIDEO INPUT BNC connectors and the AUDIO
INPUT R and L RCA 4 connectors.
2. Connect the eight 1 VIDEO OUTPUT BNC connectors and the AUDIO
OUTPUT R and L RCA 4 connectors to up to eight 1 composite video
acceptors (for example, composite video recorders).
3. If required, connect to a PC or other controller via RS-232 (see
section 6.2) or RS-232 and RS-485 (see section 6.3).
4. Connect the power cord to the mains electricity
5
.
5. Set the DIP-switches (see section 6.1).
1 From this section on, all the information is relevant also to the VS-606xl (with 6 inputs and 6 outputs), VS-804xl (with 8
inputs and 4 outputs), VS-646 (with 6 inputs and 6 outputs) and VS-848 (with 8 inputs and 8 outputs), unless noted otherwise
2 Note that you can connect up to 8 units to a PC or other RS-232 or RS-485 controller
3 Switch OFF the power on each device before connecting it to your VS-808xl. After connecting your VS-808xl, switch on its
power and then switch on the power on each device
4 The VS-606xl and 804xl also have audio RCA connectors, and the VS-646 and VS-848 have audio terminal block
connectors
5 Not illustrated in Figure 6
