VS-5x5 - Technical Specifications
8 Technical
Specifications
INPUTS:
5 composite video 1Vpp / 75
Ω on BNC connectors
5 balanced stereo audio, +4dBm (nominal)/25k
Ω on
detachable terminal blocks
OUTPUTS:
5 composite video 1Vpp / 75
Ω on BNC connectors
5 balanced stereo audio, +4dBm (nominal)/47
Ω on
detachable terminal blocks
MAX. OUTPUT LEVEL:
VIDEO: 2Vpp
AUDIO: +19dBm
BANDWIDTH (-3dB):
VIDEO: 70MHz, fully
loaded
AUDIO: 29kHz
DIFF. GAIN:
0.02%
DIFF. PHASE:
0.44Deg
K-FACTOR: <0.05%
S/N RATIO:
VIDEO: 75.1dB AUDIO:
74dB
CROSSTALK (all hostile):
VIDEO: -51.4dB @ 5MHz
AUDIO: 105dB
CONTROLS:
Audio gain level control by K-Router software, –91dB to
+26dB
COUPLING: VIDEO:
DC
AUDIO: DC at input, AC at
output
AUDIO THD + NOISE:
0.102%
AUDIO 2nd HARMONIC:
0.053%
OPERATING TEMPERATURE:
0° to +55°C (32° to 131°F)
STORAGE TEMPERATURE:
-45° to +72°C (-49° to 162°F)
HUMIDITY:
10% to 90%, RHL non-condensing
POWER SOURCE:
100-240V AC, 50/60 Hz; 112mA switching power supply
DIMENSIONS:
19" x 7" x 1U (W, D, H) rack mountable
WEIGHT:
2.7 kg (6 lbs.) approx.
ACCESSORIES:
Power cord, null-modem adapter, Windows®-based
Kramer control software, RC-IR3 infrared remote control
transmitter
Specifications are subject to change without notice at
