14 VS-5x5 - Operating the VS-5x5
7 Operating the VS-5x5
You can operate your VS-5x5 via:
•
The front panel buttons
•
RS-232/RS-485 serial commands transmitted by a touch screen system,
PC, or other serial controller
•
RC-IR3 infrared remote control transmitter
7.1 Displaying Unit Characteristics
The VS-5x5 unit characteristics are displayed in the following circumstances:
•
Immediately (and automatically) after switching on the power; and
•
When simultaneously pressing the 3 “IN” buttons 1, 2 and 3, for 3 seconds
The following information is displayed in the 7-segment display:
•
The number of IN and OUT ports (shown during the “First Display”). The
“First Display” appears initially, followed a few seconds later by the “Second
Display”
•
The firmware version number and the MACHINE # (shown during the
“Second Display”)
Figure 11: VS-5x5 Unit Characteristics
