18 VS-5x5 - Operating the VS-5x5
7.5.1 Storing an Input/Output Configuration
To store the current status in memory, do the following:
1. Press the STO button.
The STO button flashes.
2. Press one of the 10 input /output buttons (this is the setup # in which the
current status is stored). If in the CONFIRM mode, press the flashing TAKE
button to confirm the action.
The memory stores the data at that reference.
7.5.2 Recalling an Input/Output Configuration
To recall an input/output configuration, do the following:
1. Press the RCL button.
The RCL button flashes.
2. Press the appropriate Input / Output button (the button # corresponding to
the setup #). If in the CONFIRM mode, that setup configuration flashes in
the 7-segment display, together with the RCL button and the TAKE button,
and only implements after pressing the TAKE button.
The memory recalls the stored data from that reference.
Tip: If you cannot remember which of the 10 input/output configurations
is the one that you want, set the VS-5x5 to the CONFIRM mode and
manually scan all the input/output configurations until you locate it.
7.5.3 Deleting an Input/Output Configuration
To delete an input/output configuration, do the following:
1. Press the STO and RCL buttons simultaneously.
Both the STO and RCL buttons flash.
2. Press the appropriate Input / Output button.
This erases that specific input/output configuration from the memory, leaving
it empty and available.
Storing a new configuration over a previous configuration (without deleting it first) replaces the
previous configuration
