Default Communication Parameters
36
11 Default Communication Parameters
Table 4 lists the default communication parameters as used in Kramer
Electronics products.
Table 4: Default Communication Parameters
EDID
EDID data is passed between Output 1 and Input 1
RS-232
Protocol 2000 Protocol 3000 (Default)
Baud Rate: 9600 Baud Rate: 115,200
Data Bits: 8 Data Bits: 8
Stop Bits: 1 Stop Bits: 1
Parity: None Parity: None
Command Format: HEX Command Format: ASCII
Example (Output 1 to Input 1): 0x01, 0x81, 0x81, 0x81 Example (Output 1 to Input 1): #AV 1>1
Switching Protocol
P2000 -> P3000 P3000 -> P2000
Command: 0x38, 0x80, 0x83, 0x81 Command: #P2000
Front Panel: Press and hold Output 1 and
Output 3 simultaneously
Front Panel: Press and hold Output 1 and
Output 2 simultaneously
Ethernet
To reset the IP settings to the factory reset values, power cycle the device while holding in the Factory
Reset button, located on the rear panel of the unit
IP Address: 192.168.1.39
Subnet mask: 255.255.255.0
Default gateway: 192.168.1.1
TCP Port #: 5000
UDP Port #: 50000
Maximum UDP Ports: 10
Maximum TCP Ports: 4
