VP-725NA - VP-725NA Communication Protocol
63
Communication Protocol of the VP-725NA
Control Type Function Parameter
Description
Set
Get
0
1
112
15~(VT-VA-1)
Advance Input Mode: VS
0
1
113
480~1200
<= (VT-16)
Advance Input Mode: VA
0
1
114
0: Negative polarity
1: Positive polarity
Advance Input Mode: VP
0
1
115
25 < OCLK < 165
Advance Input Mode: OCLK(Integer)
0
1
116
25 < OCLK < 165
Advance Input Mode: OCLK(Decimal)
0
1
117
0: Off
1: On
Advance Input Mode: Enable
0
-
118
N/A
Advance Input Mode: Save
0
1
119
512~3071
Advance Output Mode: HT
0
1
120
32~(HS-48)
Advance Output Mode: HW
0
1
121
80~(HT-HA-12)
Advance Output Mode: HS
0
1
122
640~1920
<= (HT-92)
Advance Output Mode: HA
0
1
123
0: Negative polarity
1: Positive polarity
Advance Output Mode: HP
0
1
124
384~2047
Advance Output Mode: VT
0
1
125
2~(HS-13)
Advance Output Mode: VW
0
1
126
15~(VT-VA-1)
Advance Output Mode: VS
0
1
127
480~1200
<= (VT-16)
Advance Output Mode: VA
0
1
128
0: Negative polarity
1: Positive polarity
Advance Output Mode: VP
0
1
129
25 < OCLK < 165
Advance Output Mode: OCLK(Integer)
0
1
130
25 < OCLK < 165
Advance Output Mode: OCLK(Decimal)
0
-
131
N/A
Advance Output Mode: Save
0
-
132
N/A
Advance Output Mode: Set Current
0
1
135
0: Follow Output
1: Follow Input
HDCP Setting
0
1
136
0: Custom1
1: Custom2
2: Custom3
3: Custom4
Advance Input Mode: Custom Input
0
1
137
0: Custom1
1: Custom2
2: Custom3
3: Custom4
Advance Output Mode: Custom Output
0
1
138
0: Off
1: On
Overscan
0
1
139
0: Seamless
1: Fast
Switching Mode
0
1
140
0: Manual
1: Auto
Auto Image Mode
0
-
141
N/A
Slideshow Start
0
-
142
N/A
Slideshow Stop
0
-
143
N/A
Slideshow Pause
0
-
144
N/A
Slideshow Next
0
-
145
N/A
Slideshow Previous
0
1
146
0: Min
1: Low
2: Mid
3: Long
Slideshow
