VP-725NA - Operating the VP-725NA Presentation Switcher/Scaler 23
6.2 Switching an Input to an Output
This section describes how to switch an input to an output when the VP-725NA
operates as five independent switchers (see Section 6.2.1 ) and when it functions
as a scaler (see Section 6.2.2 ).
To switch an input to an output you have to first select the operating
mode via the SELECT button and then select the desired inputs via the
INPUT SELECTOR buttons.
6.2.1 Switching the VP-725NA as Five Independent Switchers
When operating the VP-725NA as five independent switchers, the selected input
in each group is switched to the output of that group.
To operate the VP-725NA as five independent video switchers:
Alternatively, press the AUDIO GROUP button to switch the audio signal only.
1. Press the VIDEO GROUP button.
Only the VIDEO GROUP button illuminates.
2. Press an input button to switch to the output for each of the five independent
switchers. For example, in the:
 UXGA group, press INPUT 1
 HDMI group, press INPUT 1
The HDMI Group Output is momentarily lost during switch transitions in the unit
 CV group, press INPUT 2
 YC group, press INPUT 3
 COMP group, press INPUT 4
To operate the VP-725NA as five independent audio-video switchers:
1. Press both the VIDEO GROUP and the AUDIO GROUP buttons.
Both buttons illuminate.
2. Press an input button to switch to the output for each of the five independent
switchers. The Audio follows the video.
