VP-725NA - Technical Specifications
9
Technical Specifications
INPUTS:
4 x CV 1Vpp/75Ω on BNC connectors;
4 x YC 1Vpp (Y); 0.3Vpp (C)/75Ω on 4-pin connectors;
4 x Component (Y/G, Pb/B, Pr/R or RGsB) (progressive and interlaced) on
BNC connectors;
4 x VGA (VGA through UXGA, RGBS or RGsB) on 15-pin HD connectors;
4 x HDMI on HDMI connectors;
16 x balanced stereo audio on terminal block connectors, 4dBu nominal;
microphone on a female XLR connector
GROUP
OUTPUTS:
1x CV 1Vpp/75Ω on a BNC connector;
1 x YC 1Vpp (Y); 0.3Vpp (C)/75Ω on a 4-pin connector;
1 x Component (Y/G, Pb/B, Pr/R) on BNC connectors;
1 x VGA (VGA through UXGA) on a 15-pin HD connector;
1 x HDMI on an HDMI connector;
5 x balanced stereo audio on terminal block connectors, 4dBu nominal
SCALED
OUTPUTS:
1x UXGA a 15-pin HD connector;
1 x RGBHV/YPbPr on BNC connectors;
1 x HDMI on an HDMI connector
OUTPUT
RESOLUTIONS:
Native HDMI, 640x480x60Hz, 640x480x75Hz, 800x600x50Hz, 800x600x60Hz,
800x600x75Hz, 1024x768x50Hz, 1024x768x60Hz, 1024x768x75Hz,
1280x768x50Hz, 1280x768x60Hz, 1280x720x60Hz, 1280x800x60Hz,
1280x1024x50Hz, 1280x1024x60Hz, 1280x1024x75Hz, 1366x768x50Hz,
1366x768x60Hz, 1400x1050x50Hz, 1400x1050x60Hz, 1600x1200x50Hz,
1600x1200x60Hz, 1680x1050x60Hz, 1920x1080@60Hz, 1920x1200@60Hz
(Reduced blanking), 480px60Hz, 576px60Hz, 720px50Hz, 720px60Hz,
1080ix50Hz, 1080i 60Hz, 1080px50Hz, 1080px60Hz, 1080p@24Hz,
[email protected], [email protected], [email protected], [email protected]
,
, or one of 4 Custom resolutions
If the Native HDMI is 1920x1080x60, the preferred mode is defined as
1920x1080x60(CEA-861)
CONTROL:
Front panel buttons, IR remote control, RS-232, Ethernet; with OSD and
front panel LCD
ADDITIONAL
CONTROLS:
Freeze, zoom, different selectable vertical refresh rates, output image
scaling, Picture-In-Picture, aspect ratio change, Geometry settings, text
overlay, and so on
POWER
SOURCE:
100-240V AC, 50/60Hz 38VA
DIMENSIONS:
19" x 9.3" x 3U W, D, H, rack mountable
WEIGHT:
5.5kg (12.2lbs) approx.
ACCESSORIES:
IR remote control, power cord, rack “ears”, null-modem adaptor, control
application programs via RS-232 (PC) and via Ethernet (i-Phone® and PC)
Specifications are subject to change without notice
For the most up-to-date resolution list, go to our Web site at
