46 VP-725NA - Configuring and Controlling the VP-725NA
7.2 Operating via the LCD Display
You can control the VP-725NA from the front panel high contrast LCD Display. You
can operate the VP-725NA via the LCD Display, using the:
• Front panel OSD buttons: MENU, ENTER, -, +, UP and DOWN
• Infrared remote control transmitter (see Section 7.3 ) keys: MENU, and the
navigation keys
For example, to set the Keystone to 6 via the LCD Display, using the front panel
buttons, do the following:
To keep the picture rectangular. Figure 28 illustrates how to adjust the Keystone via the OSD
Menu
1. Turn the VP-725NA unit ON, and press the OSD ON button (if selected) to
deselect it.
2. Press the appropriate front panel OSD buttons (as defined in Figure 28 ).
Figure 28: Example of How to Use the LCD Display
7.3 Operating via ETHERNET/Serial Port
To control your VP-725NA via the Ethernet/Serial Port:
• Connect the ETHERNET port of the VP-725NA to the Ethernet port of your
PC, or connect the serial port of your VP-725NA to the serial port of your
PC (see
Section 5.3 )
• Download the Ethernet Application from our Web site on
http://www.kramerelectronics.com
• Install and configure the Ethernet Application
Main Menu
Output
Main Menu
Input
Main Menu
Adjusting the Horizontal Keystone
To set the horizontal keystone, press the following:
4. Select Application
2. RIGHT, five times
1. MENU
3. ENTER
5. ENTER
7. ENTER
6. Select Horizontal Keystone
8. Press + or - buttons to set to 6
Main Menu
PIP
Main Menu
Geometry
Geometry
Application
Application
Keystone
Geometry
Horizontal Keystone
Horizontal Keystone
0
Horizontal Keystone
6
