VP-725NA - Using Text Overlay 49
Text Overlay Application Screen
Feature
Function
Parameter Setting Area
Text Color Dropdown Box
Select the Text color
Background Color Dropdown Box Set the text background color
Transparency Dropdown Box
Select On for a transparent background or Off for a non-transparent
background
Display Height Check Box Set the thickness of the background stripe (72 or 36)
Text Position – V-Position Set the vertical position of the text background on the display screen
(Top, Center or Bottom)
Communication Interface Area
Connect/Disconnect
Connect the machine or disconnect
TCP/IP Check box
When selected, set the IP Address and Port to connect via Ethernet, or
search the IP address
RS-232 Check box
When selected, set the COM port and Baud Rate (9600) to connect via
the RS-232 connector
Scrolling Mode Area
Blank Time (Sec) Dropdown Box
Set the blank delay time (from 1 to 5)
Speed Dropdown Box Set the speed at which the text moves on the display (from 1 to 5)
Mode Set to Still (fixed text) or Scrolling (text moves across the display)
Send Text Area
Message
Type the desired text in the Message box
Repeat Dropdown Box Set the number of times that the text message scrolls across the
screen (1 to 20), or set to Forever to repeat the text message
continuously
For example, set to 2 to repeat the text twice
H-Offset Dropdown Box
After selecting the Static mode, use the H-Offset box to select the
horizontal position of the text (Left Center or Right)
Start Button Click to display the text on screen
Stop Button Click to stop scrolling on screen
Quit Button Click to quit the program
Load Setting Button Click to load a previously saved setting
Save Setting Button Click to save the current setting
