Kramer Electronics VP-725NA User Manual
Page 14
VP
-72
5N
A
–
O
ver
vi
ew
9
Front Panel
#
Feature
Function
1
INPUT
SELECT
OR
Buttons
YC
Selects one of the s-Video (Y/C) sources (from 1 to 4)
2
CV
Selects one of the CV sources (from 1 to 4)
3
UXGA
Selects one of the UXGA sources (from 1 to 4)
4
HDMI
Selects one of the HDMI sources (from 1 to 4)
5
USB
Press to select the USB source
JPEG files on a USB memory stick, up to a maximum size of 2048x1536
6
COMP
Selects one of the component video sources (from 1 to 4)
7
POWER Switch
Illuminated switch for turning the unit ON or OFF
8
IR Receiver/LED
Green when ON; red when OFF
OFF in this case means that the outputs and the front-panel are disabled
9
FREEZE Button
Freezes the output video image
Applicable to the Scaler outputs only
10
PIP Button
Selects the picture-in-picture function (see
Section 6.4
11
MENU Button
Displays the OSD Menu screen (or returns to the previous level in the OSD screen)
12
ENTER Button
Moves to the next level in the OSD screen
Press for about 3 seconds to lock/unlock the front panel buttons
13
- Button
Decreases the range by one step
14
+ Button
Increases the range by one step
15
DOWN Button
Moves down one step (in the same level) in the OSD screen
16
UP Button
Moves up one step (in the same level) in the OSD screen
17
USB Connector
Connect to a USB drive to read JPEG files
18
OSD ON Button
Activates/deactivates access to the OSD Menu
The OSD ON front panel button is activated (illuminated) by default, and pressing the MENU front panel
button (or the MENU key on the infrared remote control transmitter (see
)) displays the OSD
Menu. To prevent OSD display, press the OSD ON front panel button (or the OSD key). The front panel
button no longer illuminates, and the front panel LCD now operates independently of the OSD (when the
OSD is OFF, the LCD is still operational)
19
LCD Status Display
Displays the status
