14 VP-725NA - Connecting the VP-725NA Presentation Switcher/Scaler
5 Connecting the VP-725NA Presentation
Switcher/Scaler
This section describes how to connect the VP-725NA. In particular, how to
connect the:
• VP-725NA rear panel (see Section 5.1 )
• Interlaced and progressive RGBS and RGsB inputs (see Section 5.2 )
• PC (see Section 5.3 )
• Ethernet port (see Section 5.4 )
• Audio inputs/outputs (see Section 5.5 )
Using the VP-725NA you can select any one of the 21 inputs and scale that input
to up to three scaled outputs (at the identical resolution).
5.1 Connecting the VP-725NA
To connect the VP-725NA, connect the following to the rear panel, as the example
in Figure 3 illustrates:
Always switch off the power to each device before connecting it to your
VP-725NA. After connecting your VP-725NA, connect its power and
then switch on the power to each device.
1. Connect one or more of the following video sources:
 Up to four UXGA graphics sources (for example, computers) to the
15-pin HD input connectors
These connectors also accept interlaced and progressive RGBS and RGsB
signals (see Section 5.2 )
 Up to four composite video sources (for example, DVD players) to the
BNC input connectors
 Up to four s-Video sources to the 4-pin input connectors (not illustrated
in
Figure 3 )
