62 VP-725NA - VP-725NA Communication Protocol
Communication Protocol of the VP-725NA
Control Type Function Parameter
Description
Set Get
23: 1280x960 60,
24: 1280x960 85
25: 1280x768 60
26: 1280x1024 60
27: 1280x1024 75
28: 1280x1024 76, Sun
29: 1280x1024 85
30: 1400x1050 60
31: 1400x1050 75
32: 1600x1200 60
33: 1680x1050 60
34: 1080i 60
35: 1080i 50
36: 1080p 60
37: 1080p 50
38: 720p 60
39: 720p 50
40: 480i
41: 480p
42: 576i
43: 576p
44: 1280x800 60 (R)
45: 1920x1200 60
46: 1920x1080 60
47: 1280x720 60
48: 1080p 24
49: 1280x800 60
50: 1440x900 60
51: 1440x900 60(R)
52: 1280x768 60(R)
53: 1680x1050 60 (R)
54: 1366x768 60
55: 1366x768 60 (R)
94: Custom1
95: Custom2
96: Custom3
97: Custom4
98: No Input detected
99: other
101: NTSC
102: PAL
103: PAL-M
104: PAL-N
105: NTSC 4.43
106: SECAM
107: PAL-60
0 1 105 512~3071 Advance Input Mode: HT
0 1 106 32~(HS-48) Advance Input Mode: HW
0 1 107 80~(HT-HA-12) Advance Input Mode: HS
0 1 108
640~1920
<= (HT-92)
Advance Input Mode: HA
0 1 109
0: Negative polarity
1: Positive polarity
Advance Input Mode: HP
0 1 110 384~2047 Advance Input Mode: VT
0 1 111 2~(HS-13) Advance Input Mode: VW
