TP-410 – Overview 3
3 Overview
The TP-410 UXGA-Audio-RS-232 Line Transmitter / DA is a high performance,
10-channel VGA/UXGA, audio and data to CAT 5 transmitter for high resolution
video, unbalanced stereo audio (or S/PDIF digital audio) and full-duplex RS-232
signals. The CAT 5 input can also be connected to any Kramer compatible TP
transmitter (for example, the TP-125EDID) and the CAT 5 outputs can be
connected to any Kramer compatible TP receiver (for example, the TP-126).
The TP-410 can also route bidirectional data from the RS-232, RS-485 or the
Ethernet port to any or all of the CAT 5 outputs.
TP-410 features:
•
VGA up to WUXGA (1920 x 1200) and 2k resolutions
•
A selectable local input or twisted pair input (UXGA, audio and RS-232)
•
Selectable unbalanced stereo or digital audio S/PDIF input signals
•
One local output on a 15-pin HD computer graphics video connector
•
One digital audio (S/PDIF) local output on an RCA connector, as well as one
analog audio local output on a 3.5mm mini jack
•
10 RJ-45 STP/UTP outputs
•
Compatibility with most Kramer twisted pair transmitters/receivers
•
EDID (Extended Display Identification Data) that can be copied and stored
from the display device. The display can be disconnected and later
reconnected without rebooting the operating system
•
A transmission range of up to 300ft (up to 100 meters) over STP cabling for
the input and outputs
•
Control via front panel input select button, RS-232, RS-485 and the Ethernet
•
A baud rate of up to 19,200 for sending distributed control data and
configuration commands
•
Data - Extensive Bi-Directional RS-232 handling, including embedding and
de-embedding options
