A. Technical appendix
A−3
Festo SEC−ST−48−6−P01−EN en 0606c
A.1 Technical specifications
A.1.1 SEC−ST−48−6−P01
Feature Value
Part number 548 945
Rated current I
n
1.25 A ~ 6 A adjustable
Rated voltage V
n
24...48 V DC
Operating mode Bipolar chopper driver
Operating mode 1/1 step = 200 steps per revolution
1/2 step = 400 steps per revolution
1/4 step = 800 steps per revolution
1/5 step = 1000 steps per revolution
1/8 step = 1600 steps per revolution
1/10 step = 2000 steps per revolution
1/32 step = 6400 steps per revolution
Setting the step With the dip switch
Step frequency Max. 40 kHz
Current reduction 0 or 70Ă% can be selected with dip switch
Manual movement With buttons Step+ and Stepć
LED Blue (power), red (fault)
Button RESET, Step+, Stepć, CLK Sim.
Type of connection Screw plug terminals
Method of fastening TS 35 DIN hat rail
Ambient temperature 0Ă... + 40Ă°C (... + 50° at I < 4.7 A)
Storage temperature ć10 ... +60Ă°C
Relative humidity 95 % (non condensing) Protect from humidity, no moisture condensation
Protection class IP20
Certification CE symbol
Fig. A/1:
