3. Installation
3−3
Festo SEC−ST−48−6−P01−EN en 0606c
3.1 Material
3.1.1 Manufacturer
Caution
Incorrectly prepared cables may damage the electronics
and trigger off unexpected movements of the motor.
· Test every cable in accordance with the instructions in
the section Connecting the cables" (see 3.3). Make sure
that the cables are correctly connected and that the
plugs are provided with strain−relief.
Caution
Long lines reduce immunity to interference (EMC).
· Do not exceed the maximum permitted cable lengths:
ć Control cable: 30 m
ć Power supply cable: 10 m
ć Motor cable: 10 m
Caution
Use only the cables listed below for connecting the system.
Only in this way can you guarantee the correct functioning
of the system.
Cable Designation Part number
KMTR−ST−5 Motor cable 5Ăm 530071
KMTR−ST−10 Motor cable 10Ăm 530072
KMTR−ST−x Motor cable xm
(up to max. 10Ăm) 530073
KSPC−SECST−1.5 Control cable to SPC200 530077
