Pneumatic linear cylinder
Festo 0506a English
22
Fault Remedy Possible cause
Piston does not
reach the stroke Cylinder barrel damaged Replace cylinder
reach the stroke
end position
Adjusting screw of end
position cushioning
completely closed Open adjusting screw
Foreign matter in the
cylinder Remove foreign matter, filter the
compressed air
Cylinder moves to an
external end stop Readjust end stop
Incorrect
switching during
position Temperatures too high/low Observe the permitted temperature
range of the proximity switches
position
recognition
Fault in the proximity
switch See instructions for proximity
switch
Piston without magnet
fitted Use piston with magnet
Fig. 16
11 Technical specifications
Type
Medium Filtered compressed air (filter fineness: 40 Ģm),
lubricated or non−lubricated
Mounting position As desired
End−position cushioning ć Elastic cushioning rings/plates (P cushioning)
ć Pneumatic cushioning (PPV cushioning)
ć Self−adjusting shock absorber (YSR cushioning)
ć Adjustable shock absorber (YSRJ cushioning)
Fig. 17
