Pneumatic linear cylinder
Festo 0506a English
21
9 Accessories
The necessary accessories for the individual cylinder types can be found in the
Festo Catalogue.
10 Trouble−shooting
Fault Possible cause Remedy
Uneven movement
of the piston
(cylinder jerks) Lubrication missing Lubricate with correct grease
(e.g. as per instructions with
wearing parts)
Flow control valves inserted
incorrectly If possible restrict exhaust
Piston rod dirty Clean, provide cover (after intensive
cleaning or subsequent lubrication)
Not enough supply air
(stick slip) Ĉ Keep the tubing short and select
suitable cross−sectional areas
Ĉ Select correct pressure
Ĉ Keep pressure constant
Not enough pressure Switch volume upstream
Piston seal or piston rod
seal defective Send the cylinder to Festo for
repairs or
Replace wearing parts
Guide not parallel to
direction of stroke Use a self−aligning rod coupling as
per Accessories"
(see specifications in catalogue)
