Installation procedure, Parts list – Muxlab HDMI 1x4 Distribution Hub User Manual
Page 7
© MuxLab Inc.
HDMI 1x4 Distribution Hub Installation Guide
Page 7
3.
Installation Procedure
3.1. Parts
List
The HDMI 1x4 Distribution Hub (500420) comes with
the following parts:
Base Unit
One (1) IR Sensor and one (1) IR Transmitter
One (1) 110-240V/12VDC, 1.25A Power Supply with
three interchangeable blades
Four (4) rubber feet for set-top operation
Installation Guide
Please verify that all parts are present before proceeding.
