RMS Technologies IMD23 W/ POLE DAMPING TECHNOLOGY - Manual (Page 3)

RMS Technologies Page 3 Version 1.10
IMD23/23DE Manual 12/3/2007
IMD/IMDE23 User Manual
Product:
IMD23 and IMDE23
Version: 1.10
Date: 12/3/2007
Version History
Version Date Description of Changes
1.05 6/5/2006
1.06 6/7/2007 Standardized user manual & updated
description of configuration module &
duty cycle
1.07 8/31/2007 Added configuration module info and
RoHS compliant board info. Updated
opto-isolation info.
1.08 10/26/2007 Added more troubleshooting
guidelines
1.09 11/5/2007 Added limitation on volts & currents:
24VDC and 3 Amps OR 48VDC and 2
Amps
1.10 12/3/2007 Added images of config module and
images for damping modes
