RMS Technologies

Page 23

Version 1.10

IMD23/23DE Manual

12/3/2007

NOTE:

These recommendations will provide optimal protection against EMI and RFI. The actual cable

type, wire gauge, shield type and filtering devices used are dependent on the customer’s application
and system.

Driver Supply Cable AWG Table

1 Amp (Peak)

Length (Feet)

10

25

50*

75*

100*

Minimum AWG

20

20

18

18

16

2 Amp (Peak)

Length (Feet)

10

25

50*

75*

100*

Minimum AWG

20

18

16

14

14

3 Amp (Peak)

Length (Feet)

10

25

50*

75*

100*

Minimum AWG

18

16

14

12

12

* Use the alternative methods illustrated in Examples B and C
when the cable length is ≥ 50 feet. Also, use the same current
rating when the alternate AC power is used

Driver Supply Cable Wire Size


NOTE: Always use Shielded/Twisted Pairs for the Driver DC Supply Cable, the AC Supply Cable and
the Driver to Motor Cable.
