3. DO NOT connect piping to the pump until the
pump and driver hold-down bolts have been
tightened.
4. It is suggested that expansion loops or joints be
properly installed in suction and /or discharge lines
when handling liquids at elevated temperatures, so
linear expansion of piping will not draw pump out
of alignment.
5. The piping should be arranged to allow pump
flushing prior to removal of the unit on services
handling corrosive liquids.
6. Carefully clean all pipe parts, valves and fittings,
and pump branches prior to assembly.
SUCTION AND DISCHARGE PIPING
WARNING
NPSHA must always exceed NPSHR as shown on
Goulds performance curves received with order.
(Reference Hydraulic Institute for NPSH and pipe
friction values needed to evaluate suction piping
Properly installed suction piping is a necessity for
trouble-free pump operation. Suction piping should be
flushed BEFORE connection to the pump.
1. Use of elbows close to the pump suction flange
should be avoided. There should be a minimum of
2 pipe diameters of straight pipe between the
elbow and suction inlet. Where used, elbows
should be long radius.
2. Use suction pipe one or two sizes larger than the
pump suction, with a reducer at the suction flange.
Suction piping should never be of smaller diameter
than the pump suction.
3. To prevent suction cavitation, horizontal reducers
should be eccentric with the sloping side down and
concentric for vertical applications.
5. Pump must never be throttled on suction side.
7. Separate suction lines are recommended when
more than one pump is operating from the same
source of supply.
Suction lift conditions
1. Suction pipe must be free from air pockets.
2. Suction piping must slope upwards to pump.
3. All joints must be airtight.
Suction head/Flooded suction conditions
1. An isolation valve should be installed in the suction
line at least two pipe diameters from the suction to
permit closing of the line for pump inspection and
maintenance.
2. Keep suction pipe free from air pockets.
3. Piping should be level or slope gradually
downward from the source of supply.
4. No portion of the piping should extend below pump
suction flange.
5. The size of entrance from supply should be one or
two sizes larger than the suction pipe.
6. The suction pipe must be adequately submerged
below the liquid surface to prevent vortices and air
entrainment at the supply.
Discharge piping
1. Isolation and check valves should be installed in
discharge line. Locate the check valve between
isolation valve and pump, this will permit inspection
of the check valve. The isolation valve is required
for priming, regulation of flow, and for inspection
and maintenance of pump. The check valve
prevents pump or seal damage due to reverse flow
through the pump when the driver is turned off.
2. Increasers, if used, should be placed between
pump and check valves.
3. Cushioning devices should be used to protect the
pump from surges and water hammer if quick-
closing valves are installed in system.
Final Piping Check
1. Rotate shaft several times by hand to be sure that
there is no binding and all parts are free.
2. Check alignment, per the impeller alignment
procedure outlined on pg. 28 to determine
absence of pipe strain. If pipe strain exists, correct
the piping.
!
