Team Associated SC10GT - Manual (Page 19)

19
:: Radio Tray Build (cont.) - Bag D
:: Throttle and Brake Linkage Build - Bag E
:: Throttle and Brake Linkage Build (cont.) - Bag E
Note: There are two
hole sizes in this servo
horn. Make sure you
use the correct set
when building.
!
7975
2-56
ballcup
7975
Throttle
rod
7975
Set
collar
7975
Throttle
pivot
Use
large
hole
7911
Servo
link rod
7911
Ball
cup
6925
4-40 x 1/2
shcs
7891
Chassis
brace
6918
4-40 x 1/2
bhcs
2337
Throttle
servo horn
25225
M3x3
setscrew
25225
M3x3
setscrew
7975
Set
collar
7975
Throttle
spring
4187
.030 nylon
washer
4449
4-40 x 3/16
locknut
x2
x4
Large
Small
11.5mm
Steering
servo link
!
