Team Associated SC10GT - Manual (Page 14)

14
:: Rear Suspension Build (cont.) - Bag C
:: Rear Suspension Build (cont.) - Bag C
:: Rear Suspension Build (cont.) - Bag C
7105
Rear
bumper
mount
(lower)
6926
4-40 x 5/8
shcs
89218
3x8mm
washer
6917
4-40 x 3/8
bhcs
89430
Mud flaps
7105
Rear
bumper
mount
(upper)
7104
Rear
bumper
7904
Battery
box top
6925
4-40 x 1/2
shcs
6925
4-40 x 1/2
shcs
6925
4-40 x 1/2
shcs
6925
4-40 x 1/2
shcs
x4
x4
x2
x4
x2
x2
x4
x2
Note: Wire opening in receiver
pack lid and wire hooks in
transmission case.
Racer Tip: Add foam padding
(not inluded) to cushion receiver
pack.
