Team Associated SC10GT - Manual (Page 12)

12
:: Rear Shock Tower Build - Bag B
:: Rear Shock Tower Build (cont.) - Bag B
:: Rear Shock Tower Build (cont.) - Bag B
65mm
4449
4-40 x 3/16
locknut
7217
Shock
end
7217
Pivot
ball end
7937
3.0” steel
turnbuckle
9273
1/8 x 1/4
spacer
7941
Camber
link mount
7102
Rear shock
tower
(SC10 GT)
7103
Rear
body
mounts
6332
Body
clips
7413
4-40 x 3/4
bhcs
7928
Rear arm
mount
6927
4-40 x 3/4
shcs
6915
4-40 x 5/8
fhcs
6292
4-40 x 3/8
fhcs
6926
4-40 x 5/8
shcs
6917
4-40 x 3/8
bhcs
7260
Plain nut
x2 x4
x2
x2
x2
x2
x2
x2
x2
x2
x2 x2 3897
Pivoting
body mount
x2
Build left and
right sides!
Orient the notch
to the left throughout the
car. It indicates which end
has the left hand threads!
Rear Camber
Turnbuckle
