33
SECTION: REGENERATIVE TURBINE
PAGE: 203
EFFECTIVE: 08/03/00
ISOCHEM RGT SERIES PUMP
CONSOLIDATED BILL OF MATERIALS
SUPERSEDES NEW
POSITION 3 STANDARD PUMP METALLURGIES
316SS
(A) OR (K)
ALLOY C
(C) OR (M)
DESCRIPTION QTY PART No. MATL PART No. MATL ITEM
POSITION 7 NEODYMIUM MAGNETIC COUPLING COMPONENTS (CONT)
DRIVEN MAGNET ASSY (0-RING) 1 49738 316SS 49739 ALLOY C 18
CONTAINMENT CAN 1 49672 316SS 49605 ALLOY C 19
CASING 1 49610-1 ALU 49610-1 ALU 20
BOLT, CASING *4 16722 STL 16722 STL 35
COMMON
PARTS
+ O-RING, CNTNMNT CAN *1 W209729-TFE TFE W209729-TFE TFE 28
80 METRIC FRAME COMPONENTS
DRIVE MAGNET ASSY, 80 FR 1 49733 STL 49733 STL 21
MOTOR SPOOL 1 49727 ALU 49727 ALU 29 K
BOLT, MOTOR 4 NP990415-STL STL NP990415-STL STL 25
90 METRIC FRAME COMPONENTS
DRIVE MAGNET ASSY, 90 FR 1 49734 STL 49734 STL 21
MOTOR SPOOL 1 49728 ALU 49728 ALU 29 L
BOLT, MOTOR 4 NP990478-STL STL NP990478-STL STL 25
* COMPONENT QUANTITY MAY BE CUMULATIVE OVER THE ENTIRE BILL OF MATERIALS
+ DENOTES RECOMMENDED SPARE PART.
