The Spa Screen
All Equipment Access
The Spa Screen shows all available equipment to control, as well as other features, like Invert. The display shows icons that
are related to the equipment installed on a particular spa model, so this screen may change depending on the installation.
The icon buttons are used to select and control individual devices.
Some devices, like pumps, may have more than one ON state, so the icon will change to reflect the state that the
equipment is in. Below are some examples of 2-speed Pump indicators.
Jets High Jets Low Jets Off
If the Spa has a Circ Pump, a Circ Pump Icon will appear to indicate its activity, but outside of Priming Mode, the Circ Pump
cannot be controlled directly.
NOTE: The icon for the pump that is associated with the heater (Circ or P1 Low) will have a red glow in the center when the
heater is running.
Ready in Rest Mode
Heating
Back Jets 1 Jets 2 Jets 3 Light
Invert
