BP1500 Tech Sheet
Power Requirements (D):
240VAC, 60Hz, 40A, Class A GFCI-protected service (Circuit Breaker rating = 50A max.)
4 wires (Hot–Line 1, Hot–Line 2, Neutral, Ground)
42256_A 01-09-14 4
Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,834 b2,
Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
The Set Temperature Screen
Set:
Set Temperature
101°F
High Range
Back
Dec
Inc
Set Temperature
Press Inc or Dec to modify the Set Temperature. The Set Temperature changes immediately. Press Back to return to
the Main Screen.
If you need to switch between high range and low range you need to go to the Settings Screen.
Press-and-Hold
If the Up or Down button is pressed and held, the temperature will continue to change until the button is released,
or the Temperature Range limits are reached.
