The Main Screen
Navigation
Navigating the entire menu structure is done by touching the screen.
When a text item is shown in white on the main screen, it is selectable.
The menu selections on the right side of the screen can be selected. Select one of these to enter
a different screen with additional controls.
Most menu screens time out and revert to the main screen after 30 seconds of no activity.
The only item that can be changed on the left side of the Main Screen is the Set Temperature. Touch either
the set temperature line or the water temperature to go to the Set Temperature screen. See next page.
Set: 104°F
8:32 PM
Ozone
Filter 1
Spa
Scenes
Settings
High Range 102°F
Ready in Rest Mode
Heating
Messages
At the bottom of the screen, messages may appear at various times. Some of these messages must be dismissed by the
user (see pages 22-26).
