The Main Screen
Set: 104°F
8:32 PM
Ozone
Filter 1 Spa
Scenes
Settings
High Range 102°F
Ready in Rest Mode
Heating
Spa Status
Important information about spa operation can be seen on the Main Screen.
Most features, including Set Temperature adjustment, can be accessed from this screen.
The actual water temperature and Set Temperature can be seen, and the Set Temperature can be adjusted (see page 4).
Time-of-Day, Ozone and Filter status is available, along with other messages and alerts.
The selected Temperature Range is indicated in the upper right corner.
The Jets Icon in the center will spin if any pump is running and changes color when the heater is on.
A Lock icon is visible if the panel or settings are locked.
The Menu choices on the right can be selected and the screen will change to show more detailed controls or programming
functions.
Water Temperature
Messages
Desired Temperature
Temperature Range
Pump and Heat
Menus
Lock Indicator
Status
