ExpertNet Lite Assessment Tool - User Guide

19

To Endpoint

Host name or IP address of a device that you want to be an edge device

of the new ping test path.

Protocol

Select a protocol to discover and ping this path. UDP is the

recommended protocol.

Path Tracerouting

Check this box if you want to use traceroute to discover and ping this

path. If the button is not checked, only the edge device will be pinged.
With Traceroute: The Controller collects Round Trip Time (RTT) data

from ping paths by trace-routing every path periodically. This

information is displayed in the Path Details View. The SNMP statistics

are collected only for ingress and egress interfaces of every router.

Without Traceroute: The Controller collects RTT data from ping

paths with traceroute by pinging every target directly. The SNMP

statistics are collected for all Layer 3 interfaces of the target device.

SNMP Polling

Check this box if you want the ELAT Controller to collect SNMP statistics

(CPU and interface utilization) for devices on the test path.
