8

A Steam connection
B Transport lock
C Air connection
D High pressure connection
E 2x 3 ea. Compressed air connection
F 2x clamping device (for affixing to the

boiler cart)

G Insertion depth

H Transport length
I

Hub

Measuring sheet HKF 200 K2 - smallest model

B

A

460 (I)

min. 2250 (H)

D

F

(Rp 1/4”)

C

min. 1810 (G)

(2x ø150)

(R 1 1/2”, DKL 60°)

E

(Rp 2")

28

EN
