Karcher HKF 200 K2 User Manual
Page 12
-
10
A Dampfanschluss
B Transportsicherung
C Luftanschluss
D Hochdruckanschluss
E 2x 3 Stk. Druckluftanschluss
F 2x Spannvorrichtung (zur Befestigung
an Kesselwagen)
G Einfahrtiefe
H Transportlänge
I
Hub
Maßblatt HKF 200 K2 - Größte Ausführung
780 (I)
min. 3200 (H)
min. 2760 (G)
A
(Rp 2")
D
(R 1 1/2”, DKL 60°)
(Rp 1/4”)
E
F
B
C
(2x ø150)
12
DE
