Karcher HKF 200 K2 User Manual
Page 10
-
8
A Dampfanschluss
B Transportsicherung
C Luftanschluss
D Hochdruckanschluss
E 2x 3 Stk. Druckluftanschluss
F 2x Spannvorrichtung (zur Befestigung
an Kesselwagen)
G Einfahrtiefe
H Transportlänge
I
Hub
Maßblatt HKF 200 K2 - Kleinste Ausführung
B
A
460 (I)
min. 2250 (H)
D
F
(Rp 1/4”)
C
min. 1810 (G)
(2x ø150)
(R 1 1/2”, DKL 60°)
E
(Rp 2")
10
DE
