Karcher BRC 50-70 W Bp - Manual (Page 17)

English 17
– Only use accessories and spare parts
which have been approved by the man-
ufacturer. The exclusive use of original
accessories and original spare parts en-
sures that the appliance can be operat-
ed safely and troublefree.
– At the end of the operating instructions
you will find a selected list of spare parts
that are often required.
– For additional information about spare
parts, please go to the Service section
at www.kaercher.com.
The warranty terms published by our com-
petent sales company are applicable in
each country. We will repair potential fail-
ures of your appliance within the warranty
period free of charge, provided that such
failure is caused by faulty material or de-
fects in fabrication. In the event of a warran-
ty claim please contact your dealer or the
nearest authorized Customer Service cent-
er. Please submit the proof of purchase.
We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.
The undersigned act on behalf and under
the power of attorney of the company man-
agement.
Alfred Kärcher GmbH Co. KG
Alfred Kärcher-Str. 28 - 40
D - 71364 Winnenden
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Technical specifications
Power
Nominal voltage
V 36
Battery capacity (Pack model) Ah (5h) 105
Average power consumption W 1926
Drive motor output (rated output) W 375
Suction engine output W 2 x 560
Brush engine output W 375
Vacuuming
Cleaning power, air quantity
l/s 29
Cleaning power, negative pressure kPa 17
Cleaning brushes
Working width
mm 500
Brush diameter mm 85
Brush speed 1/min 1084
Spray system
Pressure
MPa 0,69
Apply detergent solution (position A) I/min 0,9
Apply detergent solution (position B) I/min 4
Mixing ratio of fresh water/detergent A 16:1
Mixing ratio of fresh water/detergent B 64:1
Dimensions and weights
Drive speed (max.)
km/h 4,6
Drive speed (position A) km/h 2
Drive speed (position B) km/h 1
Climbing capability (max.) % 10
Theoretical surface performance (position A). m²/h 920
Theoretical surface performance (position B) m²/h 460
Fresh/dirt water reservoir volume l 74/66
Volume detergent tank A l 4,6
Volume detergent tank B l 1,25
Max. water temperature °C 60
Weight (with/ without battery) kg 295/172
Surface load kPa 3500
Length mm 1400
Width mm 700
Height mm 1100
Noise emission
Sound pressure level (EN 60704-1)
dB(A) 69,5
Machine vibrations
Vibration total value (ISO 5349)
m/s² 0,3
Spare parts
Warranty
CE declaration
Product: Floor cleaner
Type: 1.008-xxx
Relevant EU Directives
98/37/EC
2006/95/EC
2004/108/EC
Applied harmonized standards
EN 55014–1: 2006
EN 55014–2: 1997 + A1: 2001
EN 50336: 2003 + A1: 2006
CEO Head of Approbation
