- 1
Please read and comply with
these original instructions prior
to the initial operation of your appliance and
store them for later use or subsequent own-
ers.
Before first start-up it is definitely neces-
sary to read the safety indications no.
5.956-250!
Your sales outlet should be informed about
any transit damage noted when unpacking
the product.
– Warning and information plates on the
machine provide important directions
for safe operation.
– In addition to the information contained
in the operating instructions, all statuto-
ry safety and accident prevention regu-
lations must be observed.
ƽ
Danger
Risk of injury, risk of damage!
Observe the weight of the appliance when
you load it!
 Do not use a forklift.
 Use a suitable ramp or a crane to load
the appliance!
 Observe when using a ramp:
Ground clearance 70 mm.
 If the machine is delivered on a pallet,
you must create an unloading ramp us-
ing the boards provided.
You will find the instructions for this pro-
cedure on page 2 (inside of cover).
Important instruction: every board
must be attached with at least 2 screws.
ƽ
Danger
Risk of injury, risk of damage!
ƽ Danger
Risk of injury!
Danger of tipping if gradient is too high.
– The gradient in the direction of travel
should not exceed 14 %.
Danger of tipping when driving round
bends at high speed.
– Drive slowly when cornering.
Danger of tipping on unstable ground.
– Only use the machine on sound surfaces.
Danger of tipping with excessive sideways
tilt.
– The gradient perpendicular to the direc-
tion of travel should not exceed 10%.
– It is important to follow all safety instruc-
tions, rules and regulations applicable
for driving motor vehicles.
– The operator must use the appliance
properly. He must consider the local
conditions and must pay attention to
third parties, in particular children, when
working with the appliance.
– The appliance may only be used by per-
sons who have been instructed in han-
dling the appliance or have proven
qualification and expertise in operating
the appliance or have been explicitly
assigned the task of handling the appli-
ance.
– The appliance must not be operated by
children, young persons or persons
who have not been instructed accord-
ingly.
– It is strictly prohibited to take co-pas-
sengers.
– Ride-on appliances may only be started
after the operator has occupied the driv-
er's seat.
 Please remove the ignition key, when
not in use, to avoid unauthorised use of
the appliance.
 Never leave the machine unattended
so long as the engine is runningThe op-
erator may leave the appliance only
when the engine has come to a stand-
still, the appliance has been protected
against accidental movement, if neces-
sary, by applying the immobilization
brake and the ignition key has been re-
moved.
Note: Warranty claims will be entertained
only if you use batteries and chargers rec-
ommended by Kärcher.
– Always follow the instructions of the
battery manufacturer and the charger
manufacturer. Please follow the statu-
tory requirements for handling and dis-
posing batteries.
– Never leave the batteries in a dis-
charged state; recharge them as soon
as possible.
– Always keep the batteries clean and dry
to avoid creep currents. Protect the bat-
teries and avoid contact with impurities
such as metal dust.
– Do not place tools or similar items on
the battery. Risk of short-circuit and ex-
plosion.
– Do not work with open flames, generate
sparks or smoke in the vicinity of a bat-
tery or a battery charging room. Danger
of explosion.
– Do not touch hot parts of the machine
such as the drive motor (risk of burns).
– Be careful while handling battery acid.
Follow the respective safety instruc-
tions!
– Used batteries are to be disposed accord-
ing to the EC guideline 91/ 157 EWG in an
environment-friendly manner.
– Only use accessories and spare parts
which have been approved by the man-
ufacturer. The exclusive use of original
accessories and original spare parts
ensures that the appliance can be oper-
ated safely and trouble free.
– At the end of the operating instructions
you will find a selected list of spare
parts that are often required.
Contents
Safety instructions . . . . . . . EN . . 1
General notes . . . . . . . . EN . . 1
Symbols on the machine EN . . 2
Symbols in the operating in-
structions. . . . . . . . . . . . EN . . 2
Function . . . . . . . . . . . . . . . EN . . 2
Proper use . . . . . . . . . . . . . EN . . 2
Suitable surfaces. . . . . . EN . . 2
Environmental protection . . EN . . 2
Operating and Functional Ele-
ments . . . . . . . . . . . . . . . . . EN . . 3
Illustration of sweeper . . EN . . 3
Operating field. . . . . . . . EN . . 3
Function keys . . . . . . . . EN . . 3
Indicator lamps and display EN . . 4
Before Startup. . . . . . . . . . . EN . . 4
Fold up the cab . . . . . . . EN . . 4
Lock/ release parking brake EN . . 4
Moving sweeper without en-
gaging self-propulsion . . EN . . 4
Moving sweeper by engag-
ing self-propulsion . . . . . EN . . 4
Start up . . . . . . . . . . . . . . . . EN . . 4
General notes . . . . . . . . EN . . 4
Inspection and maintenance
work. . . . . . . . . . . . . . . . EN . . 4
Before Startup. . . . . . . . . . . EN . . 4
Safety notes regarding the
batteries . . . . . . . . . . . . EN . . 4
Charge the batteries . . . EN . . 4
Operation . . . . . . . . . . . . . . EN . . 5
Adjusting driver's seat . . EN . . 5
Programme selection . . EN . . 5
Starting the machine . . . EN . . 5
Drive the machine . . . . . EN . . 5
Sweeping mode . . . . . . EN . . 6
Emptying waste container EN . . 6
Turn off the appliance . . EN . . 6
Transport. . . . . . . . . . . . . . . EN . . 6
Storage . . . . . . . . . . . . . . . . EN . . 6
Shutdown . . . . . . . . . . . . . . EN . . 6
Maintenance and care . . . . EN . . 7
General notes . . . . . . . . EN . . 7
Cleaning . . . . . . . . . . . . EN . . 7
Maintenance intervals . . EN . . 7
Maintenance Works . . . EN . . 7
EC Declaration of Conformity EN . . 9
Warranty . . . . . . . . . . . . . . . EN . . 9
Troubleshooting . . . . . . . . . EN . 10
Technical specifications . . . EN . 11
Safety instructions
Risk of hearing impairment.
Always use proper ear-pro-
tection aids while working
with the appliance.
General notes
Unloading tips
Weight (without batteries) 840 kg*
Weight (with batteries) 1,300
kg*
* If upgrade kits are installed, the weight is
respectively higher.
Drive mode
Battery-operated machines
Accessories and Spare Parts
14 EN
