Page 23
-
10
Î Fill up fresh water reservoir.
Î Unscrew the filter cup of the fresh water
filter and check for water leaking.
Î If there is no water leaking out, clean
the filter insert.
Î Tighten the filter cup.
Î Pull the suction hose off the cover of the
dirt water reservoir.
Î Start the cleaning process.
At the latest after 2 minutes, detergent
solution should be emitted.
Î Insert the suction hose into the cover of
the fresh water reservoir.
Brushes do not turn
Reset fuse of brush drive.
Operator
Check the brushes for blockage due to foreign particles, remove them if found.
Operator
No or very little detergent so-
lution gets added
Check level of detergent solution in the fresh water tank; refill, if required.
Operator
Open locking tap for fresh water.
Operator
Air in the pump for detergent, ventilate pump (see "Clearing faults").
Operator
Select a more intensive cleaning program.
Operator
Check fresh water sieve and filter; clean if required.
Operator
The cleaning head does not
remain lowered.
Install the brushes.
Operator
Rectify faults
Ventilate the detergent solution pump
Accessories
Description
Part no.:
Description
Piece
Machine
requires
piece
Battery changing kit
8.601-121.0
consists of: battery trough, cable set, locking set, 2
transport cars
1
1
Battery *
6.654-141.0
12V/105 A, maintenance-free (Gel),
1
3
Charger *
6.654-229.0
36V, for maintenance-free batteries
1
1
* Only suited for appliances with maintenance-free batteries (gel).
Accessories BD 60/95 RS
Description
Part no.:
Description
Piece
Machine
requires
piece
Disk brush, blue (medium, standard)
8.600-018.0
For cleaning slightly dirtied or sensitive floors.
1
2
Disk brush, grey (hard)
8.600-020.0
For cleaning heavily dirtied floors.
1
2
Driver plate
8.600-017.0
For intake of pads.
1
2
Disc pad, red (medium)
6.369-826.0
For cleaning slightly dirtied floors.
5
2
Disc pad, green (hard)
6.369-827.0
For cleaning heavily dirtied floors.
5
2
Disc pad, black (very hard)
6.369-828.0
For cleaning heavily dirtied floors.
5
2
Accessories B 95 RS with R 65 cleaning head
Description
Part no.:
Description
Piece
Machine re-
quires piece
Brush roller, red (medium, stand-
ard)
6.906-935.0
Also for regular cleaning of heavily dirtied floors.
1
2
Brush roller, white (soft)
6.906-981.0
For polishing and cleaning sensitive floors.
1
2
Brush roller, orange (high/ low)
6.906-982.0
For scrubbing structured floors (safety tiles, etc.).
1
2
Brush roller, green (grit)
6.906-983.0
For thoroughly cleaning heavily dirtied floors and for
removing the coating (for e.g. of wax, acrylate).
1
2
Brush roller, black (very hard)
6.906-984.0
For thoroughly cleaning heavily dirtied floors and for
removing the coating (for e.g. of wax, acrylate).
1
2
Pad roller shaft
4.762-433.0
For intake of roller pads.
1
2
Roller pad, white (very soft)
6.369-389.0
For fine-polishing floors.
20
96
Roller pad, red (medium)
6.369-456.0
For cleaning slightly dirtied floors.
20
96
Roller pad, green (hard)
6.369-455.0
For cleaning normal to heavily dirtied floors.
20
96
Roller pad, yellow (soft)
6.369-454.0
For polishing floors.
20
96
23
EN
