- 8
Î Open the clamping lock and remove the
strap.
Î Take out the vacuum lips.
Note
The vacuum lips can be turned thrice till all
edges are worn off. After that you need a
new vacuum lip.
Î Turn the vacuum lip or replace and in-
sert it back into the vacuum bar and
align.
Î Insert the strap and close the clamping
lock. The tension must just be sufficient
to hold the vacuum lip without wrinkling.
Adjust the clamping lock, as required.
Î Lower the cleaning head.
Î Turn key to "0" and remove it.
1 Stopper
Î Loosen the end and adjust it in such a
way that the lower edge of the spray
guard is approx. 3 mm from the floor.
Î Tighten the stopper.
1 side spray guard
Î Lift the cleaning head.
Î Turn key to "0" and remove it.
Î Raise the side spray guard and remove
it from the side.
Î Turn the unlocking lever of the sliding
brush in an anti-clockwise direction -
the brushes will fall downward and can
be pulled outward at the bottom of the
device.
Î Hold the new brush under the cleaning
head.
Î Turn the unlocking lever of the sliding
brush in clockwise direction and press
the brush upward.
Î Release the unlocking lever and check
that the brush is sitting properly.
Î Replace the spray-guard.
Î Repeat process on the opposite side.
1 Pipe
2 Sieve with floater ball
Î Clean the sieve from the outside and
rinse it.
Î Check the mobility of the floater ball.
If it is too dirty:
Î Hold the pipe firmly and pull out the
sieve from the pipe.
Î Clean sieve and ball.
Î Hold the pipe firmly and reinsert the
sieve.
1 Fresh water filter
2 Locking valve for fresh water
Î Close locking tap of fresh water.
Î Unscrew the filter cup.
Î Clean filter inlay or replace if too dirty.
Î Replace the filter cup.
Î Open locking tap.
In case of danger of frost:
Î Empty the fresh and dirt water reser-
voirs.
Î Store the appliance in a frost-protected
room.
Mount splash guard
Replacing the Disk Brushes
Maintenance tasks - all types
Cleaning the floater
Clean the fresh water filter
Frost protection
21 EN
