DTC1000/4000/4500 Toolbox User Guide - LINUX (L001593 Rev 1.1) 18
Mag Lo-Co Voltage Offset
This option changes the voltage going the magnetic head.
(Note: This is factory set and should not be changed unless
directed by a technician.)
OLED Contrast (Display contrast)
Use this option to increase or decrease the contrast of the
printer OLED (if applicable).
Resin Heat Adjust Use this adjustment for Black resin text and barcodes if
they appear faded or too light/dark.
(Note: This control can be helpful for fine-tuning the
transfer of resin text and bar codes.)
Head Resistance This is factory set. If the main board or the Print head is
replaced then adjust this number.
Locate the Print head Setting Number on the bottom of the
Print head.
The number reads R=XXXX
Head Home Offset This is a calibration driven value and should not be
adjusted. If the Print head assembly is replaced then this
value may need to be adjusted.
(Note: This is factory set and should not be changed unless
directed by a technician.)
Head Contact Offset This is a calibration driven value and should not be
adjusted. If the Print head assembly is replaced then this
value may need to be adjusted.
(Note: This is factory set and should not be changed unless
directed by a technician.)
Erase Heat Offset Adjust the Erase temperature for the rewriteable cards as
needed.
Increase the Current Setting to cause more heat to be
used in the erasing process.
OR
Decrease the Current Setting to cause less heat to be
used in the erasing process.
(Note: Erase Heat Offset provides user ability to control
the Print head heat level when the Erase Operation is
performed. Appropriate heat levels should be applied for
the proper erase process. This setting should be adjusted
for proper erasure.)
Write Heat Offset Adjust the Write temperature for the rewriteable cards as
