82363-901 C.1
INSTALLATION GUIDE 3 ©2009 - 2012 HID Global Corporation. All rights reserved.
Door / Reader Module
EDWM-M
1.3 Tamper (Reader Interface Board)
The Reader Tamper + and - are implemented allowing a connection for an open collector external tamper from a reader, such
as iCLASS.
Note: Connect P2, Pin 2 (GND) from the Reader Interface Board to the same ground as the reader power, if the reader is not
powered by the 12 VDC output of the module.
1.4 Door Interface Board Groups 1 and 2
1.4.1 Group 1
Following are the inputs when the unit is configured for Group 1.
Input Port Pin
AC - P3 Pin3
AC + P3 Pin 4
BATT - P3 Pin 5
BATT + P3 Pin 6
REX - P3 Pin 7
REX + P3 Pin 8
Door Mon - P3 Pin 9
Door Mon + P3 Pin 10
1.4.2 Group 2
Following are the inputs when the unit is configured for Group 2.
Input Port Pin
Input 4 - P3 Pin3
Input 4 + P3 Pin 4
Input 3 - P3 Pin 5
Input 3 + P3 Pin 6
Input 2 - P3 Pin 7
Input 2 + P3 Pin 8
Input 1 - P3 Pin 9
Input 1 + P3 Pin 10
