Alliance Laundry Systems UW35AV - Manual (Page 19)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Specifications and Dimensions
17 F232228
IMPORTANT: Drawing is not to scale.
PHM664N
Figure 7
PHM664N
0.75 in.
(19 mm)
48 in.
(1219 mm)
48 in.
(1219 mm)
46.25 in.
(1181 mm)
0.75 in.
(19 mm)
0.75 in.
(19 mm)
7 in.
(178 mm)
61.5 in.
(1562 mm)
10 in.
(254 mm)
55.47 in.
(1409 mm)
48.94 in.
(1243 mm)
23.25 in.
(591 mm)
23.25 in.
(591 mm)
15 in.
(381 mm)
15.25 in.
(387 mm)
FRONT OF MACHINE
UW125AV
