Specifications and Dimensions
15 F232228
IMPORTANT: Drawing is not to scale.
PHM662N
Figure 5
PHM662N
0.75 in.
(19 mm)
0.75 in.
(19 mm)
1.25 in.
(32 mm)
36 in.
(914 mm)
2 in.
(51 mm)
46.8125 in.
(1189 mm)
44.8125 in.
(1138 mm)
39.25 in.
(997 mm)
34.125 in.
(867 mm)
0.75 in.
(19 mm)
31.625 in.
(803 mm)
35.625 in.
(905 mm)
2 in.
(51 mm)
9 in.
(229 mm)
0.75 in.
(19 mm)
21.4375 in.
(544 mm)
UW60AV
4.8125 in.
(122 mm)
1.25 in.
(32 mm)
FRONT OF MACHINE
